Scrap Grapples

Scrap Grapples: The Powerful Attachment for Efficient Scrap & Debris Handling

A Scrap Grapple is a hydraulic attachment designed to transform excavators, telehandlers, or wheel loaders into robust scrap-handling machines. Engineered to grip, lift, and transport bulky or irregularly shaped materials—including scrap metal, concrete debris, wood, and industrial waste—it eliminates the need for manual loading or multiple machines. Available in two primary designs (orange peel and clamshell), scrap grapples excel in scrapyards, demolition sites, steel mills, and recycling facilities, where speed, precision, and durability are critical.

Types & Designs

• Orange Peel Grapple: Features 4–6 curved steel “fingers” arranged in a circular pattern, ideal for gripping loose, scattered scrap (e.g., car bodies, mixed metal parts). Its open design allows easy release of materials into bins or crushers.
• Clamshell Grapple: Consists of two hinged “jaws” (like a giant clam shell), perfect for lifting large, dense objects (e.g., steel beams, concrete slabs, bales of waste). Some models include a rotating head (360°) for precise positioning.

How It Works

Powered by the host machine’s hydraulic system, the scrap grapple uses:

• Hydraulic Cylinders: Control jaw/finger opening (width: 0.8–3 meters) and closing force (5–50 tons) for secure gripping.
• Reinforced Structure: Hardox® 450 steel body and tungsten carbide-tipped teeth resist abrasion from sharp or abrasive materials.
• Quick Coupler Compatibility: Attaches seamlessly to 5–50 ton excavators, telehandlers, or loaders via standardized mounting plates.
• Optional Rotation: Integrated slewing rings enable 360° rotation for flexible material placement (e.g., stacking scrap in tight spaces).
  Operators manage all functions via the host machine’s cab joysticks, adjusting grip strength and movement in real time.

Key Advantages

• Powerful Grip: High-tensile steel construction generates 5–50 tons of clamping force—secures even slippery or jagged scrap.
• Durability: Hardox® steel body, heat-treated teeth, and sealed hydraulic components withstand daily abuse in harsh environments.
• Versatility: Handles diverse materials (metal, concrete, wood, waste) with interchangeable tooth designs (sharp for metal, blunt for debris).
• Efficiency: Lifts 1–5 tons per cycle, 5–10x faster than manual loading—reduces labor costs and project timelines.
• Precision Placement: Rotating heads (optional) and fine hydraulic control enable accurate stacking, sorting, or feeding into crushers.
• Low Maintenance: Sealed bearings and corrosion-resistant coatings minimize downtime; easy-to-replace wear parts.

Technical Highlights

• Gripping Force: 5–50 tons (model-dependent for mini to large excavators)
• Opening Width: 800–3,000 mm (31–118 inches, orange peel/clamshell variants)
• Capacity: 0.5–3 m³ (18–106 ft³, depending on material density)
• Compatible Machines: 5–50 ton excavators, telehandlers (10–30 ft reach), wheel loaders (2–10 m³ bucket capacity)
• Material: Hardox® 450 steel body, tungsten carbide-tipped teeth, reinforced hydraulic hoses
• Rotation: Optional 360° slewing ring (for clamshell models)
• Weight: 800–6,000 kg (1,764–13,228 lbs, balanced for host machine stability)
• Hydraulic Flow: 40–200 L/min (matches standard excavator auxiliary circuits)
• Operating Temperature: -30°C to 50°C (-22°F to 122°F)

Applications

• Scrapyards: Sort and load mixed metal scrap (cars, appliances, structural steel) into shredders or bins.
• Demolition Sites: Clear concrete debris, rebar, and wood from collapsed structures for disposal/recycling.
• Steel Mills: Handle raw scrap metal (blooms, billets) for melting in furnaces.
• Recycling Facilities: Separate and feed recyclables (plastic, paper bales, e-waste) into processing lines.
• Construction Waste Management: Collect and transport site debris (concrete chunks, bricks) to landfills or recycling centers.
• Landfills: Compact and arrange bulky waste (tires, furniture) to maximize space efficiency.

From bustling scrapyards to post-demolition cleanup, the scrap grapple combines brute strength with precision—making it indispensable for industries focused on efficient material handling and waste reduction. Its ability to adapt to diverse scrap types and tight workspaces solidifies its role as a top-tier attachment for modern heavy equipment.
